IP-A1SC15
Original price was: ฿23,300.00.฿21,000.00Current price is: ฿21,000.00.
- Power Source : PoE+ (IEEE802.3at Class 4), PoE (IEEE802.3af Class 3)
- Amplifier Rated Output : 15 W (at PoE+ powered), 8 W (at PoE powered)
- Sensitivity : 112 dB (1 W, 1 m) (500 Hz – 2.5 kHz, peak level)
การจัดส่งสินค้า
-
จัดส่งโดยบริษัทของเรา
หากสินค้ามีพร้อมจัดส่ง
ระยะเวลา 1-2 วัน
ฟรี (ตามเงื่อนไข)
-
Express DHL , Flah , Kerry
หากสินค้ามีพร้อมจัดส่ง
ระยะเวลา 1-3 Days
ฟรี (ตามเงื่อนไข)
-
Warranty 1 year
More details
-
Free 30-Day returns
More details
Description
ลำโพงฮอร์น แบบ IP ยี่ห้อ TOA รุ่น IP-A1SC15
| Power Source | PoE+ (IEEE802.3at Class 4), PoE (IEEE802.3af Class 3) |
|---|---|
| Power Consumption | 22 W (at PoE+ powered, rated output) 12.95 W (at PoE powered, rated output) 5 W (IEC62368-1) |
| Amplifier Rated Output | 15 W (at PoE+ powered), 8 W (at PoE powered) |
| Sensitivity | 112 dB (1 W, 1 m) (500 Hz – 2.5 kHz, peak level) |
| Max. Sound Pressure Level | 124 dB (at PoE+ powered, 15 W, 1 m) (500 Hz – 2.5 kHz, peak level) 121 dB (at PoE powered, 8 W, 1 m) (500 Hz – 2.5 kHz, peak level) |
| Frequency Response | 280 Hz – 12.5 kHz |
| Audio Codec | PCMU (G.711u), PCMA (G.711a), G.722 |
| Broadcasting Mode | SIP Broadcasting Mode: PCMU/PCMA/G.722 Multicast Broadcasting Mode: PCMC/PCMA/G.722, Max. 10 ports VMS Broadcasting Mode: Audio Backchannel, PCMU Internal Message Broadcasting Mode Note: Each broadcast model can be assigned an order of priority using the Priority Setting function. |
| Internal Messages | Max. 20 messages (Max. recording capacity: 80 MB) Supported file formats: WAV file: 8/16/44.1/48 kHz sampling frequency, 8/16 bit, monaural/stereo MP3 file: 32/44.1/48 kHz sampling frequency, 64-320 kbps, CBR/VBR, monaural/stereo Repeat count: 1-99 sec, Interval time: 0-99 sec Trigger: Contol Input or Remote API (HTTP) |
| Network I/F | 100BASE-TX, MDI/MDI-X, RJ-45 |
| Network Protocol | TCP/IP, UDP, HTTP, RTP, ARP, ICMP, RTSP, SIP (RFC3261) |
| Control Input | 2 channels, no-voltage make contact inputs, open voltage: 5 V DC, short-circuit current: 2 mA or less, removable terminal block (3 pins) |
| Control Output | 1 channel, open collector output, withstand voltage 30 V DC, control current: 10 mA or less, removed terminal block (3 pins) |
| Indicator | LAN LINK / ACT (green), STATUS (orange) |
| Dust/Water Protection | IP66 |
| Operating Temperature | -30 °C to +55 °C |
| Operating Humidity | 90 %RH or less (no condensation) |
| Finish | Horn flare and body: Aluminum, off-white (RAL 9010 equivalent), paint Reflector horn: ABS resin, off-white (RAL 9010 equivalent) Rear Cover: PC resin, off-white (RAL 9010 equivalent), paint Bracket, Screws and bolts: Stainless Steel |
| Dimensions | 222 (W) x 211 (H) x 276 (D) mm |
| Weight | 1.4 kg |
| Accessory | Rear Cover x 1, Removable terminal plug (3 pins) x 2 |
| Option | Speaker mount bracket: SP-131, SP-201, SP-301 Pole Band: YS-60B |
