ส่งด่วนภายใน 72 ชม. กรุงเทพฯและปริมณฑล
IP-A1PC238
Original price was: ฿20,000.00.฿17,400.00Current price is: ฿17,400.00.
- Power Source : PoE (IEEE802.3af Class 3)
- Amplifier Rated Output : 8 W
- Sensitivity : 94 dB (1 W, 1 m) (500 Hz – 5 kHz, pink noise)
การจัดส่งสินค้า
หากสินค้ามีพร้อมจัดส่ง
ระยะเวลา 1-2 วัน
ฟรี (ตามเงื่อนไข)
หากสินค้ามีพร้อมจัดส่ง
ระยะเวลา 1-3 Days
ฟรี (ตามเงื่อนไข)
More details
More details
Description
ลำโพงติดเพดานแบบ IP ยี่ห้อ TOA รุ่น IP-A1PC238
| Power Source | PoE (IEEE802.3af Class 3) |
|---|---|
| Power Consumption | 12.95 W (rated output) 5 W (IEC62368-1) |
| Amplifier Rated Output | 8 W |
| Sensitivity | 94 dB (1 W, 1 m) (500 Hz – 5 kHz, pink noise) |
| Max. Sound Pressure Level | 103 dB (8 W, 1 m) |
| Frequency Response | 60 Hz – 20 kHz (peak -20 dB) |
| Audio Codec | PCMU (G.711u), PCMA (G.711a), G.722 |
| Broadcasting Mode | SIP Broadcasting Mode: PCMU/PCMA/G.722, P2P/SIP Server Connection Multicast Broadcasting Mode: PCMU/PCMA/G.722 Auto codec recognition, 20 ports VMS Broadcasting Mode: ONVIF Audio Backchannel, PCMU Internal Message Broadcasting Mode Note: Each broadcast model can be assigned an order of priority using the Priority Setting function. |
| Internal Messages | Max. 20 messages (Max. recording capacity: 80 MB) Supported file formats: WAV file: 8/16/44.1/48 kHz sampling frequency, 8/16 bit, monaural/stereo MP3 file: 32/44.1/48 kHz sampling frequency, 64-320 kbps, CBR/VBR, monaural/stereo Repeat playback: Playcount (1-10 times), Duration (5-3600 sec) or Timer (from Start time to End time) Interval time: 0-99 sec, Delay time: 0-99 sec Trigger: Contol Input or Remote API (HTTP) |
| Network I/F | 100BASE-TX, Auto MDI/MDI-X, RJ-45 connector |
| Network Protocol | TCP/IP, UDP, HTTP, RTP, RTSP, RTCP, ARP, ICMP, IGMPv3, NTP, SIP (RFC3261) |
| Control Input | 2 channels, no-voltage make contact inputs, open voltage: 5 V DC, short-circuit current: 2 mA or less, removable terminal block (6 pins) |
| Control Output | 1 channel, open collector output, withstand voltage 30 V DC, control current: 10 mA or less, removable terminal block (6 pins) |
| Indicator | LINK / ACT (green), STATUS (orange) |
| Clock Accuracy | ±13 seconds per month |
| Time Adjustment | Manual time setting, Time adjustment by NTP server |
| Power Outage Protection Period | 24 hours (RTC time retention, at 40 °C) |
| Dimensions for Fixing Hole | Mounting hole: Ø200 ±2 mm Ceiling thickness: 5 – 25 mm |
| Speaker Mounting Method | Spring Clamp |
| Operating Temperature | 0 °C to +50 °C |
| Operating Humidity | 90 %RH or less (no condensation) |
| Finish | Frame: Steel plate, white (RAL 9016 equivalent), paint Grill: Steel net, white (RAL 9016 equivalent), paint |
| Dimensions | Ø230 x 89 (D) mm |
| Weight | 880 g |
| Accessory | Pattern paper x 1, Removable terminal plug (6 pins, preinstalled on the unit) x |
